Engineered for Strength. Designed for Speed.

Constructed from high-tensile steel, the QuickClip Fencing System outperforms leading metal alternatives and offers guaranteed strength for decades, without the deterioration that affects timber posts.
Title

No.2170-INTER-GV18

QuickClip™ Intermediate Steel Fence Post

Unrivalled Strength

Fully formed 'Y' profile, high tensile steel and additional reinforced plate, provides up to double the strength of typical market alternatives.

Long-Term Value

Maintenance free with a 40-year lifetime guarantee.

Consistent Performance

Unlike timber, QuickClip™ won't rot, split, or weaken in the ground.

Fast & Easy Installation

Drive directly into the ground, no expensive machinery required.
Title

40 Year Guarantee

Click to view terms

CLICK TO CONTACT US

FIND A STOCKIST

CLICK HERE TO SHOP QUICKCLIP

Strength where it matters most.

No.2170-STRAINSYSTEM

QuickClip™ Heavy Duty Straining System

Every secure and long-lasting fence starts and ends with a reliable straining system. The QuickClip™ Heavy Duty End Strainer has been engineered to deliver exceptional holdingh power and long-term performance, making it the foundation of long-lasting agricultural fencing.

Alt image Alt image Alt image

QuickClip™ Heavy Duty Fencing System Includes:

2170-POST - Straining Post

2170-STRUT - Support Strut

2170-BASE - Pressure Base Plate

2170-PIN - Drive-In Security Pin

Guaranteed Strength

Extra heavy-duty construction for maximum durability.

Consistent Performance

QuickClip™ provides a consisten anchor point throughout the fence's life, unlike timber strainers that often need replacing and require maintenance.

40 Year Guarantee

Hot dip galvanising to to BS EN ISO 1461 for long-term corrosion resistance.

No Hazardous Treatments

Safe, non-toxic steel alternative to creosote, or chemically-treated timber posts.

Suitable for all Ground

Additional plates can be affixed to the post for use in soft ground.

40 Year Guarantee

Click to view terms

CLICK TO CONTACT US

FIND A STOCKIST

CLICK HERE TO SHOP QUICKCLIP
Title

Testimonials

QuickClip Merchandise

Fill out the QuickClip Installation Testimonial Form below and receive your very own FREE Merchandise from Perry QuickClip.

CLICK HERE FOR QUICKCLIP TESTIMONIAL FORM
Title

Additional Products

No.2019
Intermediate Petrol Post Driver

SEE ONLINE

No.2019L
Strainer Petrol Post Driver


SEE ONLINE

No.487
Manual Post Rammer


SEE ONLINE

No.2190
Strainer Wire Clip


SEE ONLINE

No.2171
Ring Split-Pin Insulator


SEE ONLINE

No.2172
Joule Shield Steel Post Pinlock Insulator

SEE ONLINE

No.2175
Standard Intermediate Post Cap

SEE ONLINE

No.2175M
Meaty Intermediate Post Cap

SEE ONLINE
Title

Frequently Asked Questions

What is the recommended spacing of the intermediate posts?

Post spacing depends on ground conditions, livestock pressure, fence height, wire type and wind exposure, but as a guide and based on typical installation under normal conditions we suggest:
Mild-steel netting 2.5 m – 3.0 m
High-tensile netting 3.5 m – 4.5 m.
Please Note* Installers should reduce spacing where required, including:
• Sloping or uneven ground
• High wind exposure
• Soft or sandy soils
• High livestock pressure

Is a Straining Post required at every change in direction of the fence run?

It is recommended that a straining post is required at every change in direction of the fence run. However for very slight changes in direction, a straining post may not be required depending on tension and ground conditions.

Is the system available under the Grant scheme in England?

Yes, as an all-metal fencing system, QuickClip is fully compliant with FG1/FG2/FG9 specifications

How to apply:
1. Speak to the local Rural Payments Agency (RPA) or Natural England representative.
2. Apply under the Countryside Stewardship scheme (FG1 or FG2).
3. Include QuickClip fencing in your application.

What is the thickness of the Straining Post?

QuickClip straining posts are manufactured from heavy-duty 6mm galvanised steel, designed to withstand high tension and long-term use in agricultural environments.

How far from the ground do the Straining Posts stand?

The main Straining Post is installed approximately 800mm into the ground, leaving the post standing 1600mm above ground.

How far from the ground do the intermediate posts stand?

The main Straining Post is installed approximately 700mm into the ground, leaving the post standing 1100mm above ground.

Is the system suitable for Barbed Wire?

Yes. QuickClip is suitable for use with barbed wire, either as a standalone fence or as a topping wire above netting.

Is the system suitable for Electric Wire?

Yes. The Intermediate Posts include various holes specifically for electric wire insulators.

Can I use tractor to knock intermediates into ground?

Yes, a tractor-mounted post driver can be used. However, one of the advantages of the QuickClip system is that intermediate posts can easily be driven by hand, removing the need for tractors or heavy machinery.

What is the best tool to knock intermediates into the ground?

A hand-held mechanical post driver is the most efficient tool for installing QuickClip intermediate posts. A manual post driver is also typically sufficient

What is the best tool to knock the Strainer Posts into the ground?

A hand-held mechanical post driver is typically sufficient for driving Strainer Posts into the ground, however  a tractor-mounted post driver may be preferred depending on the ground type, accessibility and job size.

Do I need to concrete the Strainer Posts into the ground?

Strainer posts do not require concreting when installed correctly.
In very soft, wet or unstable ground, concreting may be considered at the installer’s discretion.

Can the intermediated be removed once in the ground?

Intermediate posts are designed for permanent installation, however with appropriate tools the can be removed and repositioned if required, for example during fence realignment or replacement.

How to register for the guarantee?

Guarantees need to be registered online through this link: QuickClip 40-Year Limited Warranty – Perry Group

This must be completed withing the first 90 days of purchase or within 30 days of installation.
